OBS Settings for Dual-PC Psynaps Super Stream System

The Dual-PC RTMP Stream setup is getting more popular, here are my settings!

UPDATE HERE (Jan. 2017):
http://www.psynapticmedia.com/psynaps-obs-settings-twitch-2017/

I am releasing the super stream system for download (coming soon).
In the mean time, check out the Psynaps Stream Guides!
Button_Psynaps_Stream_guides

Background on the Psynaps Super Stream System

For the background and historical information about this multi-PC RTMP streaming system, see the “Super Stream System by Psynaps” page.

This Guide Contains

Here I will explain how my dual-PC streaming system (Super Stream System) is configured for streaming to Twitch. I included screenshots of my exact OBS configuration on both computers, along with some helpful alternative settings that I also use. I have been using this system for 2 years, and it works great, now I am sharing the settings! This system allows me to offset some of the workload onto the second PC, giving my main PC more CPU for games. This results in a higher quality stream, and higher FPS for me in games.

I will show the:

  • OBS screenshots and explanations of the Game PC settings (first PC)
  • OBS Studio screenshots and explanations the Encoding PC settings (second PC)
  • Settings that Psynaps uses currently to stream to twitch with explanations (requires NVENC supported nvidia card)
  • Alternative settings that are more compatible (x264, no need for nvidia NVENC)

Requirements

  • I use Two PCs, one for gaming (Main Gaming PC), one for streaming (Encoding PC).
  • Psynaps Super Stream System (download available to Hall of Famers and project supporters, just ask me). This runs on the encoding computer.
  • Capture card NOT required. This system works with the Psynaps Super Stream System, which is a downloadable server program that allows super high quality multi-PC streaming without a capture card.

Psynaps OBS Settings Main PC (Config #1 – NVENC)

****************************
